Territory ‘Steppe’

The sepia tones and colours that evoke timeless, wide open spaces and distinct seasonal changes of the steppe are what inspired Cemintel Territory™ Steppe.

The Territory range is classified AS 5113 EW (External Walls) for fire compliance. Find out more here.

Cemintel Territory™ is created for you – a natural cladding range that comes from Japanese values of simplicity, nature and quality. These prefinished cladding panels simulate materials like stone, timber, concrete, metal, tiles and smooth render in a sophisticated way to enhance building façades, without the ongoing maintenance.

The dry, grassy and arid plains of the steppe have distinct seasonal changes in temperature, with cold winters and warm summers. These extremes are reflected in the sepia tones seen on the steppe, colours that evoke timeless, wide open spaces.

Category: Facades & Cladding
Store availability: Cabramatta, Katoomba
Online Enquiry

Features

  • Prefinished and available in a variety of colours and simulated textures.
  • Provides a ventilated cavity to keep your building dry.
  • NichiGuard® stain resistant and self cleaning coating available on most panels^.
  • Machined with a complementary tongue and groove profile that easily fit together.
  • Choice of simple aluminium or colour matched, preformed corners.
  • Minimal ongoing maintenance required.
  • Simple clip fixing system that goes together like Meccano® from the starter strip.
  • Platinum coating technology protects against UV damage and colour fade.
  • Compressible sealing strip factory bonded onto the tongue profile to form a weather resistant joint.

CEMINTEL TERRITORY™ PANELS ARE CEMENT BONDED FIBROUS WOOD PARTICLE CLADDING PRODUCTS THAT ARE PRESSED WITH SURFACE TEXTURE AND PREFINISHED USING A DURABLE MULTI-LAYER PAINT PROCESS TO ACHIEVE A RANGE OF TEXTURES, FINISHES AND DESIGNS. THE LONG HORIZONTAL EDGE OF THE PANEL IS MACHINED WITH A COMPLEMENTARY TONGUE AND GROOVE PROFILE AND A COMPRESSIBLE SEALING STRIP IS BONDED ONTO THE TONGUE WHICH ENABLES THE PANELS TO FIT NEATLY TOGETHER TO FORM A WEATHER RESISTANT JOINT.

Cemintel Territory panels are manufactured in Japan to the Japanese Industrial Standard JIS A 5422 (fibre reinforced cement sidings) and are classified as a Type A, Grade 2 (fibre cement) sheet in accordance with ASTM C1186.

APPLICATIONS

Result
Applications Façades & Cladding, Internal Linings
Type of Building Structure Residential Housing Buildings within the scope of AS4055, Commercial & Other
Wet Areas No

PANEL – DIMENSIONAL & GEOMETRICAL CHARACTERISTICS

Dimensional/Geometrical Characteristic Specification Manufacturing Tolerance Relevant Standard
Panel Width 470mm (overall width), 455mm (effective cover) +/- 1mm JIS A 5422
Panel Length 3030mm +/- 1mm JIS A 5422
Panel Thickness 16mm +/- 1.2mm JIS A 5422
Profile Tongue & Groove
Perpendicularity/squareness of edges
Weight (typical) 17.9 – 21.8kg/m2 Based on dry weight. 24.6kg to 30kg per sheet (or 17.9 to 21.8kg per m2) depending on sheet design (NB 2 x panels per pack)
Layout Options Horizontal, Vertical (NB not all panels have matching preformed vertical corners – check Design and Installation Guide for details)
Jointing Concealed

PANEL – STRENGTH & MOISTURE RELATED PROPERTIES

Physical Property Result Relevant Standard
Modulus of Rupture (Wet) > 7 Mpa ASTM C 1186
Modulus of Elasticity (Wet) 2.2 – 3.35 Gpa EN 12467
Density (Oven Dry) 1191Kg/m3 (average) ASTM C 1186
Water Vapor Diffusion
Water Tightness (24hrs) No water droplet ASTM C 1186
Water Absorption (Saturated – 48hrs) 13.9% (average) ASTM C 1186
Moisture Content (EMC) 7-9% ASTM C 1186
Moisture Movement 0.07% (average) ASTM C 1186

NB/ The above test results relate to coated panels unless otherwise specified (ie edges are sealed for testing to reflect the characteristic of sheets as delivered & in accordance with installation instructions). In-house testing as per ASTM C 1186.

PANEL – OTHER DURABILITY/WEATHER RESISTANCE INDICATORS

Test Result Relevant Standard
Heat Rain PASSED (25 Cycles) ASTM C 1186
Freeze Thaw PASSED (50 Cycles) ASTM C 1186
Warm Water Resistance PASSED (56 days) ASTM C 1186
Soak Dry PASSED (50 Cycles) EN 12467

PANEL – FINISH CHARACTERISTICS

Characteristic Result Relevant Standard
Finish Prefinished
Coating Type Nichiguard Coating – applied to all panels with the exception of Savanna Mist and Savanna Shade. Provides an anti-staining, self cleaning function. Silica particles in the coating attract water from the atmosphere to form a thin molecular film, so that airborne contaminants do not reach the panel surface itself. Rain water that runs down the wall washes contaminants away. (Platinum Coating)
Colour Bodied No
Paint Type Silicon Acrylic Emulsion
UV Resistance N/A N/A
Formaldehyde Emission Rate Meets Green Building Council Office Design IEQ-14 Requirements for <0.1mg/m2/hr*
*Refers to results obtained for Woodlands Teak
ASTM D5116
VOC Emission Rate Meets Green Building Council Office Design IEQ-14 Requirements for <0.5mg/m2/hr*
*Refers to results obtained for Woodlands Teak
ASTM D5116
Spectral Reflectivity Values Solar Reflectance % Solar Absorption % Basix Colour Relevant Standard
Steppe Tundra 22.9 77.1 ±0.7 Dark ASTME 903-12
Steppe Montane 6.1 93.9 ±0.6 Dark ASTME 903-12
Steppe Alpine 63.9 36.1 ±1.9 Light ASTME 903-12

PANEL – FIRE RESISTANCE, THERMAL & ACCOUSTIC PROPERTIES

Characteristic Result Relevant Standard
FIRE RESISTANCE
Combustibility Suitable for use in applications where non-combustible materials are specified by the Deemed to Satisfy Provisions of the 2016 BCA Vol 1 Amendment 1 Clause C1.9 (2015 BCA Vol Clause C1.12)
Fire Hazard Properties Group 1 Av Specific Extinction Area <250 AS/NZ 3837
Classification 1 AS/NZ 3837
Surface Burning Characteristics Flame spread index = 0; Smoke developed = 0 ASTM E84
THERMAL CONDUCTIVITY
Thermal Conductivity (λ-Factor) 0.26 W/mk (average) JIS A 1412
Thermal Expansion Co-efficient N/A
ACOUSTIC VALUE
Sound reduction (depends on construction) N/A N/A

SYSTEM SOLUTIONS

Characteristic Result Relevant Standard
Within Scope of AS4055? Yes
Wind Loading – Residential housing buildings within the scope of AS4055 N1, N2, N3, N4, N5 (horizontal), N6 (horizontal), C1, C2, C3 (horizontal), C4 (horizontal steel frame only)
Weatherproofing When installed horizontally – has passed testing at a serviceability wind pressure of +3.72kPa and -3.72kPa, and an ultimate wind pressure of +6kPa and -6kPa.
When installed vertically – has passed testing at a serviceability wind pressure of +1.6kPa and -2.2kPa, and an ultimate wind pressure of +2.6kPa and -3.3kPa.
AS 4284
Cyclonic Conditions Horizontal installation/ tested which passed at 4.5kPa (using long clip) and 2.7kPa (using short clip). AS 4040.3
Fire Resistance Limits (FRLs) Up to 90/90/90 Refer to Gyprock® The Red Book™
Bushfire Construction BAL 40 (Construction for Bushfire Attack Level 40 for an external wall) AS 1530.8.1
Acoustic Acoustic solutions of up to RW/RW+CTR 52/43 are detailed Refer to Gyprock® The Red Book™
Thermal Thermal solutions of up to RT(sum)/RT(win) 2.8/3 are detailed Refer to Gyprock® The Red Book™

FIXING

Characteristic
Maximum Span (Stud Spacing) Up to 600mm
DIRECT FIX
Nail to Timber Frame No
Screw to Timber Frame No
Screw to Steel Frame No
INDIRECT FIX
Timber Frame Yes
Steel Frame Yes
Masonry Frame Yes
EXPOSED FASTENERS
Screw Yes (limited)
Rivet No
Nail Yes (limited)
CONCEALED FASTENERS
Clip Yes
Countersunk Screw/Nail No
Adhesive, Split Batten, etc. No
Hidden by Overlapping Panel No
Flush Jointed (Taped) No

WARRANTY

10 Years
