Cemintel Territory™ Woodlands is inspired by a habitat where trees are dominant, overlapping and interlinking to form a canopy that filters light and creates a mosaic of light and shadow on the ground below.
The Territory range is classified AS 5113 EW (External Walls) for fire compliance. Find out more here.
Cemintel Territory™ is created for you – a natural cladding range that comes from Japanese values of simplicity, nature and quality. These prefinished cladding panels simulate materials like stone, timber, concrete, metal, tiles and smooth render in a sophisticated way to enhance building façades, without the ongoing maintenance.
Woodlands are a habitat where trees are the dominant plant form. The individual trees overlap and interlink to form a canopy, filtering the light and creating a mosaic of light and shadow on the ground below.
- Prefinished and available in a variety of colours and simulated textures.
- Provides a ventilated cavity to keep your building dry.
- NichiGuard® stain resistant and self cleaning coating available on most panels^.
- Machined with a complementary tongue and groove profile that easily fit together.
- Choice of simple aluminium or colour matched, preformed corners.
- Minimal ongoing maintenance required.
- Simple clip fixing system that goes together like Meccano® from the starter strip.
- Platinum coating technology protects against UV damage and colour fade.
- Compressible sealing strip factory bonded onto the tongue profile to form a weather resistant joint.
CEMINTEL TERRITORY™ PANELS ARE CEMENT BONDED FIBROUS WOOD PARTICLE CLADDING PRODUCTS THAT ARE PRESSED WITH SURFACE TEXTURE AND PREFINISHED USING A DURABLE MULTI-LAYER PAINT PROCESS TO ACHIEVE A RANGE OF TEXTURES, FINISHES AND DESIGNS. THE LONG HORIZONTAL EDGE OF THE PANEL IS MACHINED WITH A COMPLEMENTARY TONGUE AND GROOVE PROFILE AND A COMPRESSIBLE SEALING STRIP IS BONDED ONTO THE TONGUE WHICH ENABLES THE PANELS TO FIT NEATLY TOGETHER TO FORM A WEATHER RESISTANT JOINT.
Cemintel Territory panels are manufactured in Japan to the Japanese Industrial Standard JIS A 5422 (fibre reinforced cement sidings) and are classified as a Type A, Grade 2 (fibre cement) sheet in accordance with ASTM C1186.
|Applications||Façades & Cladding, Internal Linings|
|Type of Building Structure||Residential Housing Buildings within the scope of AS4055, Commercial & Other|
PANEL – DIMENSIONAL & GEOMETRICAL CHARACTERISTICS
|Dimensional/Geometrical Characteristic||Specification||Manufacturing Tolerance||Relevant Standard|
|Panel Width||470mm (overall width), 455mm (effective cover)||+/- 1mm||JIS A 5422|
|Panel Length||3030mm||+/- 1mm||JIS A 5422|
|Panel Thickness||16mm||+/- 1.2mm||JIS A 5422|
|Profile||Tongue & Groove|
|Perpendicularity/squareness of edges|
|Weight (typical)||17.9 – 21.8kg/m2 Based on dry weight. 24.6kg to 30kg per sheet (or 17.9 to 21.8kg per m2) depending on sheet design (NB 2 x panels per pack)|
|Layout Options||Horizontal, Vertical (NB not all panels have matching preformed vertical corners – check Design and Installation Guide for details)|
PANEL – STRENGTH & MOISTURE RELATED PROPERTIES
|Physical Property||Result||Relevant Standard|
|Modulus of Rupture (Wet)||> 7 Mpa||ASTM C 1186|
|Modulus of Elasticity (Wet)||2.2 – 3.35 Gpa||EN 12467|
|Density (Oven Dry)||1191Kg/m3 (average)||ASTM C 1186|
|Water Vapor Diffusion|
|Water Tightness (24hrs)||No water droplet||ASTM C 1186|
|Water Absorption (Saturated – 48hrs)||13.9% (average)||ASTM C 1186|
|Moisture Content (EMC)||7-9%||ASTM C 1186|
|Moisture Movement||0.07% (average)||ASTM C 1186|
NB/ The above test results relate to coated panels unless otherwise specified (ie edges are sealed for testing to reflect the characteristic of sheets as delivered & in accordance with installation instructions). In-house testing as per ASTM C 1186.
PANEL – OTHER DURABILITY/WEATHER RESISTANCE INDICATORS
|Heat Rain||PASSED (25 Cycles)||ASTM C 1186|
|Freeze Thaw||PASSED (50 Cycles)||ASTM C 1186|
|Warm Water Resistance||PASSED (56 days)||ASTM C 1186|
|Soak Dry||PASSED (50 Cycles)||EN 12467|
PANEL – FINISH CHARACTERISTICS
|Coating Type||Nichiguard Coating – applied to all panels with the exception of Savanna Mist and Savanna Shade. Provides an anti-staining, self cleaning function. Silica particles in the coating attract water from the atmosphere to form a thin molecular film, so that airborne contaminants do not reach the panel surface itself. Rain water that runs down the wall washes contaminants away. (Platinum Coating)|
|Paint Type||Silicon Acrylic Emulsion|
|Formaldehyde Emission Rate||Meets Green Building Council Office Design IEQ-14 Requirements for <0.1mg/m2/hr*
*Refers to results obtained for Woodlands Teak
|VOC Emission Rate||Meets Green Building Council Office Design IEQ-14 Requirements for <0.5mg/m2/hr*
*Refers to results obtained for Woodlands Teak
|Spectral Reflectivity Values||Solar Reflectance %||Solar Absorption %||Basix Colour||Relevant Standard|
|Woodlands Teak||17.2||82.8 ±0.5||Dark||ASTME 903-12|
|Woodlands Smoked||8.5||91.5 ±0.3||Dark||ASTME 903-12|
|Woodlands Limed||51.5||48.5 ±1.5||Light/Medium||ASTME 903-12|
|Woodlands Whitewash||23.8||76.2 ±0.7||Dark||ASTME 903-12|
|Woodlands Ebony||7.7||92.3 ±0.6||Dark||ASTME 903-12|
PANEL – FIRE RESISTANCE, THERMAL & ACCOUSTIC PROPERTIES
|Combustibility||Suitable for use in applications where non-combustible materials are specified by the Deemed to Satisfy Provisions of the 2016 BCA Vol 1 Amendment 1 Clause C1.9 (2015 BCA Vol Clause C1.12)|
|Fire Hazard Properties||Group 1 Av Specific Extinction Area <250||AS/NZ 3837|
|Surface Burning Characteristics||Flame spread index = 0; Smoke developed = 0||ASTM E84|
|Thermal Conductivity (λ-Factor)||0.26 W/mk (average)||JIS A 1412|
|Thermal Expansion Co-efficient||N/A|
|Sound reduction (depends on construction)||N/A||N/A|
|Within Scope of AS4055?||Yes|
|Wind Loading – Residential housing buildings within the scope of AS4055||N1, N2, N3, N4, N5 (horizontal), N6 (horizontal), C1, C2, C3 (horizontal), C4 (horizontal steel frame only)|
|Weatherproofing||When installed horizontally – has passed testing at a serviceability wind pressure of +3.72kPa and -3.72kPa, and an ultimate wind pressure of +6kPa and -6kPa.
When installed vertically – has passed testing at a serviceability wind pressure of +1.6kPa and -2.2kPa, and an ultimate wind pressure of +2.6kPa and -3.3kPa.
|Cyclonic Conditions||Horizontal installation/ tested which passed at 4.5kPa (using long clip) and 2.7kPa (using short clip).||AS 4040.3|
|Fire Resistance Limits (FRLs)||Up to 90/90/90||Refer to Gyprock® The Red Book™|
|Bushfire Construction||BAL 40 (Construction for Bushfire Attack Level 40 for an external wall)||AS 1530.8.1|
|Acoustic||Acoustic solutions of up to RW/RW+CTR 52/43 are detailed||Refer to Gyprock® The Red Book™|
|Thermal||Thermal solutions of up to RT(sum)/RT(win) 2.8/3 are detailed||Refer to Gyprock® The Red Book™|
|Maximum Span (Stud Spacing)||Up to 600mm|
|Nail to Timber Frame||No|
|Screw to Timber Frame||No|
|Screw to Steel Frame||No|
|Adhesive, Split Batten, etc.||No|
|Hidden by Overlapping Panel||No|
|Flush Jointed (Taped)||No|
