Rigid Air Barrier

Cemintel Rigid Air Barrier is designed for use with Cemintel’s pressure equalised cladding systems to produce effective weather-resistant façades.

Rigid Air Barrier is a 6mm fibre cement panel consisting primarily of Portland Cement, cellulose fibres, sand and water. It is sealed on the face and edges using Cemintel’s proven Ceminseal embedded micro waterblock technology, which repels water, preventing water penetrating into the panel and hence providing a durable sheet that will not rot, swell or warp when correctly installed. By protecting against wind and rain, it allows work to be carried on inside the building prior to cladding being installed. Being fibre cement, Cemintel Rigid Air Barrier may be used where a non-combustible material is required by the BCA.

Category: Facades & Cladding

Store availability: Cabramatta, Katoomba

Online Enquiry

Product Overview
Technical Specifications
Downloads

Features

Helps produce effective weather-resistant façades
Provides a durable sheet that will not rot, swell or warp
May be used where a non-combustible material is required by the BCA
Sealed using Ceminseal embedded micro waterblock technology
Protects against wind and rain allowing work on inside the building prior to cladding installation

APPLICATIONS

	Result
Applications	Rigid Air Barrier
Type of Building Structure	Residential Housing Buildings within the scope of AS4055, Commercial & Other
Wet Areas	No

PANEL – DIMENSIONAL & GEOMETRICAL CHARACTERISTICS

Dimensional/Geometrical Characteristic	Specification	Manufacturing Tolerance	Relevant Standard
Panel Dimensions	1200mmW x 3000mmL x 6mmD	Width +0 -3 mm Length +0 -4 mm Thickness +0.5 -0 mm
Profile	Square Edge
Perpendicularity/squareness of edges	2mm/linear meter
Weight (typical)	10kg/m2
Layout Options	Vertical & Horizontal
Jointing	Tape

PANEL – STRENGTH & MOISTURE RELATED PROPERTIES

Physical Property	Result	Relevant Standard
Modulus of Rupture (Wet)	> 9 MPa	AS2908.2
Modulus of Elasticity (Wet)	3-5 GPa	AS2908.2
Density (Oven Dry)	1350 kg/m3	AS2908.2
Water Vapor Permeance	0.25µg/N.S	ASTM E96
Water Resistance	4.02 MN .s/g	AS2908.2
Water Tightness (24hrs)	No water droplet	AS2908.2
Water Absorption (Saturated – 48hrs)	30 wt%	ASTM C 1186
Moisture Content (EMC)	< 7 Wt %	ASTM C 1186
Moisture Movement	0.06%	ASTM C 1186

PANEL – OTHER DURABILITY/WEATHER RESISTANCE INDICATORS

Test	Result	Relevant Standard
Heat Rain	PASSED (25 Cycles)	AS2908.2
Freeze Thaw	PASSED (50 Cycles)	AS2908.2
Warm Water Resistance	PASSED (56 days)	AS2908.2
Soak Dry	PASSED (25 Cycles)	AS2908.2

PANEL – FINISH CHARACTERISTICS

Characteristic	Result	Relevant Standard
Finish	Sealed (on face/orange colour)
Coating Type	CeminSeal®

Spectral Reflectivity Values	Solar Reflectance %	Solar Absorption %	Basix Colour	Relevant Standard
Rigid Air Barrier				N/A

PANEL – FIRE RESISTANCE, THERMAL & ACCOUSTIC PROPERTIES

Characteristic	Result	Relevant Standard
FIRE RESISTANCE
Combustibility	Suitable for use in applications where non-combustible materials are specified by the Deemed to Satisfy Provisions of the 2016 BCA Vol 1 Amendment 1 Clause C1.9 (2015 BCA Vol Clause C1.12)
THERMAL CONDUCTIVITY
Thermal Conductivity (λ-Factor)	≈ 0.2704 W/m.K.
Thermal Expansion Co-efficient	0.005-0.01mm/mK
ACOUSTIC VALUE
Sound reduction (depends on construction)	N/A

SYSTEM SOLUTIONS

Characteristic	Result	Relevant Standard
Within Scope of AS4055?	Yes
Wind Loading – Residential housing buildings within the scope of AS4055	N1, N2, N3, N4, N5, N6, C1, C2, C3, C4
Weatherproofing	Suitable for use as part of an external cladding with a pressure equalised cavity system for wind pressures up to 7KPa	N/A
